LEKI Sherpa XL, Khumbu & Makalu Replacement Lower Section

Product code LESECL86 - Black Anodized

£21.95
This item is sold out

Description

LEKI Code: LESECL86 14 mm Lower Section 490 mm Length Black Anodized Speed Lock 2 (SL2) 16/14 mm Section Production Era: Approximately 2006–2012
This 14 mm lower section is the correct factory replacement for the LEKI Sherpa XL, Khumbu, and Makalu trekking poles in the SL2 black anodized configuration, all built on the standard 18/16/14 mm three-section telescopic geometry. The Speed Lock 2 (SL2) external lever provides fast one-motion height adjustment, clamping directly against the outer wall of the 14 mm section. The black anodized finish (colour code 033) and 490 mm printed length are shared across this family and are the defining specifications for this section. From the broad ridges of Exmoor to long approach routes in the Cairngorms, the Sherpa XL, Khumbu, and Makalu were established names in LEKI’s trekking range across this era. When the lower section is bent, cracked, or the SL2 lever collar no longer holds under load, this replacement restores the original geometry and locking function. The 490 mm printed length is specific to this SL2 family — verify the printed marking on your existing lower section before ordering. Sold as a single section.

► Full Technical Specifications
LEKI Spare Part Code LESECL86
Article Code 81 05 11 14 0490 33
Section Position Lower — tip end
Section Diameter 14 mm
Printed Length 490 mm — check this on your existing section before ordering
Section Profile 16/14 mm
Material Aluminium
Finish / Colour Code Black Anodized (033)
Locking System Speed Lock 2 (SL2) — external lever; open lever outward to release, close firmly to lock
Construction Telescopic (Vario) — 3-section
Production Era Approximately 2006–2012. The 14 mm diameter and 490 mm printed length are specific to this configuration — verify both on your existing section before ordering.
Sold As Single section
► Compatible Poles & Fitting Guide
This lower section is confirmed compatible with the following LEKI poles. Always verify the printed length and diameter on your existing lower section before ordering.
Sherpa XL — article codes 6362028
Khumbu — article codes 6492043, 65220431
Makalu — article codes 6492849, 65228491
Additional confirmed compatible article codes (model names not established from available sources): 65220191, 6322829, 6362152
Diameter check: This is a 14 mm section. Measure the diameter of your existing lower section with calipers before ordering. A section measuring a different diameter requires a different spare part.
Length verification: The 490 mm printed length is the defining specification — measure the printed marking on your existing lower section, not the physical length. A section showing any other printed length requires a different spare part.
Fitting: Open the Speed Lock 2 lever to release the existing section, then slide it out from the tip end. Insert the new section and close the Speed Lock 2 lever firmly to secure. The lever should close flush with the collar.
Lock engagement: If the lever does not close fully or the section moves under load, tighten the adjuster nut on the clamp collar clockwise in quarter-turn increments until the lever locks securely. Do not overtighten.
Not sure? Email photos of the full pole, the damaged section, and any visible article codes to [email protected] so the correct replacement can be confirmed before ordering.
► Not Compatible With
SL2 poles with a lower section of a different diameter — the lever collar will not seat correctly on a different diameter and the pole will not lock securely
SL2 poles with a lower section of a different printed length — SL2 lower sections of other printed lengths are different spare parts and are not interchangeable
Speed Lock 1 (SL1) poles — earlier external lever generation; SL2 sections are not interchangeable with SL1 lever collars
SLS (Super Lock System) poles — internal twist-lock mechanism; entirely different locking interface from the SL2 external lever system

BEFORE YOU ORDER — FOUR-POINT CHECK
Printed length: Must read 490 mm on your existing lower section — check the printed marking, not a physical measurement
Diameter: Confirm 14 mm lower section diameter — measure with calipers. This is a 16/14 mm profile section
Locking system: Confirm Speed Lock 2 (SL2) — the lever opens outward from a hinged collar. If your pole has an SL1 lever or an SLS internal twist-lock collar, this section is not suitable
Construction: 3-section telescopic (Vario) with 16/14 mm section profile — verify the profile matches before ordering
Unsure? Email photos of the full pole, the damaged section, and any visible article codes to [email protected] for confirmation before ordering

Trade Mark of Manufacturer: LEKI

Manufacturer & EU Responsible Person: Leki Lenhart GmbH, Karl-Arnold-Stabe 30, 73230 Kirchheim/Teck, Germany

Contact: www.leki.com
