LEKI Trail, Eagle & Voyager Replacement Lower Section
Product code LESECL93 - Dark Anthracite
£21.95
This item is sold out
Description
LEKI Code: LESECL93 14 mm Lower Section 490 mm Length Dark Anthracite Anodized SLS (Super Lock System) 16/14 mm Section Production Era: Approximately 2006–2012
This 14 mm lower section is the correct factory replacement for the LEKI Trail, Eagle, and Voyager trekking poles in dark anthracite aluminium, all built on the standard 18/16/14 mm three-section telescopic geometry used across LEKI’s mainstream trekking range during this era. These poles used the SLS (Super Lock System) internal twist-lock mechanism for height adjustment — rotate the lower section anti-clockwise to release, set height, rotate clockwise to lock — with no external lever or tool required. The dark anthracite anodized finish (colour code 056) and 490 mm printed length are shared across this family and are both defining specifications for this replacement section. From the high moorland paths of Dartmoor to the long valley walks through the Yorkshire Dales, these poles were part of LEKI’s core trekking range for many years. When the lower section is bent, cracked, or the SLS mechanism no longer holds under load, this replacement restores the original geometry and locking function precisely. The 490 mm printed length is specific to this configuration — verify the printed marking on your existing lower section before ordering. Sold as a single section.
► Full Technical Specifications
| LEKI Spare Part Code | LESECL93 |
| Article Code | 81 05 03 14 0490 56 |
| Section Position | Lower — tip end |
| Section Diameter | 14 mm |
| Printed Length | 490 mm — check this on your existing section before ordering |
| Section Profile | 16/14 mm |
| Material | Aluminium |
| Finish / Colour Code | Dark Anthracite Anodized (056) |
| Locking System | SLS — Super Lock System; internal twist-lock; rotate anti-clockwise to unlock, clockwise to lock; no external lever |
| Construction | Telescopic (Vario) — 3-section |
| Production Era | Approximately 2006–2012. The 14 mm diameter and 490 mm printed length are specific to this configuration — verify both on your existing section before ordering. |
| Sold As | Single section |
► Compatible Poles & Fitting Guide
This lower section is confirmed compatible with the following LEKI poles. Always verify the printed length and diameter on your existing lower section before ordering.
✓ Trail — article codes 6402021, 65020211, 65320111
✓ Eagle — article codes 6402017, 65020171, 65320171
✓ Voyager — article codes 6402011, 65020111
✓ Additional confirmed compatible article codes (model names not established from available sources): 6432021, 6432214, 6432223
✓ Diameter check: This is a 14 mm section. Measure the diameter of your existing lower section with calipers before ordering. A section measuring a different diameter requires a different spare part.
✓ Length verification: The 490 mm printed length is the defining specification — measure the printed marking on your existing lower section, not the physical length. A section showing any other printed length requires a different spare part.
✓ Fitting: Rotate the existing lower section anti-clockwise to disengage the SLS lock, then slide it out from the tip end. Insert the new section and rotate clockwise until the lock engages with firm resistance. Test by applying downward load before use.
✓ Lock engagement: The SLS mechanism should engage with a firm, positive resistance when rotated clockwise. If the section rotates freely or fails to hold under load, the internal SLS collar may require assessment or replacement.
✓ Not sure? Email photos of the full pole, the damaged section, and any visible article codes to [email protected] so the correct replacement can be confirmed before ordering.
► Not Compatible With
✗ SLS poles with a lower section of a different diameter — sections of a different diameter will not seat correctly in the SLS collar and the pole will not lock securely
✗ SLS poles with a lower section of a different printed length — SLS lower sections of other printed lengths are different spare parts and are not interchangeable
✗ Speed Lock 1 (SL1) poles — external lever clamping system; SLS twist-lock sections are not interchangeable with SL1 lever collars
✗ Speed Lock 2 (SL2) poles — external lever clamping system; entirely different interface from the SLS internal twist-lock mechanism
BEFORE YOU ORDER — FOUR-POINT CHECK
✓ Printed length: Must read 490 mm on your existing lower section — check the printed marking, not a physical measurement
✓ Diameter: Confirm 14 mm lower section diameter — measure with calipers. This is a 16/14 mm profile section
✓ Locking system: Confirm SLS (Super Lock System) — the section rotates to lock and unlock with no external lever. If your pole has a Speed Lock lever (SL1 or SL2), this section is not suitable
✓ Construction: 3-section telescopic (Vario) with 16/14 mm section profile — verify the profile matches before ordering
✓ Unsure? Email photos of the full pole, the damaged section, and any visible article codes to [email protected] for confirmation before ordering
