LEKI External Lever System (ELS) Replacement Middle Section — 14 mm / 440 mm
Product code LESECM11 - Nature Anodized
£19.95
Description
LESECM1114 mm Middle Section440 mm LengthNature/Silver AnodizedExternal Lever System (ELS)14 mm SectionProduction Era: Approximately 1990–2006
This LEKI replacement middle section uses the External Lever System (ELS) locking mechanism. At 14 mm diameter and 440 mm printed length, it is the correct replacement for the models listed below. The middle section connects the upper section assembly to the lower section and is the most frequently replaced component after extended field use. No specific model names have been confirmed for this article code in our current records. Before ordering, verify the printed length on your existing section reads 440 mm and the diameter is 14 mm. The locking system must be External Lever System (ELS). If unsure, email photos to [email protected] before ordering.
► Full Technical Specifications
| LEKI Spare Part Code | LESECM11 |
| Article Code | 81 02 06 14 0440 36 |
| Section Position | Middle — connects upper to lower section |
| Section Diameter | 14 mm |
| Printed Length | 440 mm (check this on your existing section before ordering) |
| Section Profile | 14 mm constant-diameter tube |
| Material | Aluminium |
| Finish / Colour Code | Nature/Silver Anodized (36) |
| Locking System | External Lever System (ELS) |
| Construction | 3-section telescopic (Vario) |
| Production Era | Approximately 1990–2006. Verify printed length and diameter on your existing section before ordering. |
| Sold As | Single section |
► Compatible Poles & Fitting Guide
No specific model names are confirmed for this section code in our current records. The following article codes are associated with this section — if your pole carries one of these codes, this section may be compatible.
✓ Associated article codes (model names not established): 32172, 42172, 52172, 32171, 42136, 42435, 52136, 52435, 52257, 42147, 42443, 52141, 42401, 52401, 52236, 52235 — if your pole carries one of these codes, email photos of the full pole and existing section to [email protected] to confirm compatibility before ordering.
✓ Spare parts support: LEKI typically supports spare parts for approximately 10 years from product launch. Contact [email protected] or call +44 (0)1250 710414 to confirm availability.
✓ To fit: open the external lever on the upper section, seat the middle section fully, then close the lever to lock. Ensure the section is fully engaged before locking. Dry before storage.
✓ Article code check: the article code is usually printed on the section tube itself. Cross-reference with the codes listed above before ordering. If your code is not listed, email [email protected] with photos for confirmation.
✓ Post-fit care: dry the section fully before storage; do not store the pole collapsed with moisture trapped inside the tube. Keep the lever mechanism clean and free from grit or debris.
✓ Fitting check: after fitting, extend the pole to working height and apply gentle downward pressure — the section should hold its position without slipping or creaking. Re-adjust the lever if needed before use.
✓ LEKI UK service: for warranty queries, complex repairs, or any section you cannot identify with certainty, contact LEKI UK: [email protected] | +44 (0)1250 710414.
► Not Compatible With
✗ Speed Lock Plus (SPL) or Speed Lock 2 (SL2) poles — Speed Lock sections are not interchangeable with External Lever System sections
✗ SLS (Super Lock System) poles — twist-lock system; ELS sections are not compatible
✗ Folding (FX) poles — entirely different construction, these sections do not apply
✗ Poles with a different section specification — this section is 14 mm diameter and 440 mm
BEFORE YOU ORDER — FOUR-POINT CHECK
✓ Printed length: the printed length on your existing middle section must read 440 mm
✓ Diameter: section diameter must be 14 mm (check the markings on the existing section)
✓ Locking system: confirm your poles use External Lever System (ELS)
✓ Construction: confirm 3-section telescopic (Vario); not suitable for folding (FX) or 2-section poles
