LEKI Carbonlite Replacement Middle Section
Product code LESECM24 - Black
£39.95
Description
LESECM2414 mm Middle Section462 mm LengthBlack AnodizedSpeed Lock Plus (SPL)14 mm SectionProduction Era: Approximately 2013–2019
The Carbonlite is a LEKI trekking pole using the Speed Lock Plus (SPL) locking system, which operates via a Speed Lock Plus lever with a rotary tension adjustment collar. This 14 mm middle section at 462 mm length is the correct replacement for this model. The middle section connects the upper section assembly to the lower section and is the most frequently replaced component after extended field use. Before ordering, confirm the printed length on your existing middle section reads 462 mm and that the section diameter is 14 mm. The locking system must be Speed Lock Plus (SPL). If you are unsure of compatibility, email photos of the full pole and existing section to [email protected] before ordering.
► Full Technical Specifications
| LEKI Spare Part Code | LESECM24 |
| Article Code | 81 02 09 14 0462 03 |
| Section Position | Middle — connects upper to lower section |
| Section Diameter | 14 mm |
| Printed Length | 462 mm (check this on your existing section before ordering) |
| Section Profile | 14 mm constant-diameter tube |
| Material | Aluminium |
| Finish / Colour Code | Black Anodized (3) |
| Locking System | Speed Lock Plus (SPL) |
| Construction | 3-section telescopic (Vario) |
| Production Era | Approximately 2013–2019. Verify printed length and diameter on your existing section before ordering. |
| Sold As | Single section |
► Compatible Poles & Fitting Guide
This section is confirmed compatible with the following LEKI pole models. Verify your article code before ordering.
✓ Carbonlite — confirmed compatible
✓ Spare parts support: LEKI typically supports spare parts for approximately 10 years from product launch. Contact [email protected] or call +44 (0)1250 710414 to confirm availability.
✓ To fit: open the SPL lever, seat the section fully, close the lever and adjust tension collar if needed. Ensure the section is fully seated before locking. Dry before storage.
✓ Article code check: the article code is usually printed on the section tube itself. Cross-reference with the codes listed above before ordering. If your code is not listed, email [email protected] with photos for confirmation.
✓ Post-fit care: dry the section fully before storage; do not store the pole collapsed with moisture trapped inside the tube. Keep locking components clean and free from grit or debris.
✓ Fitting check: after fitting, extend the pole to working height and apply gentle downward pressure — the section should hold its position without slipping or creaking. Re-adjust the locking mechanism if needed before use.
✓ LEKI UK service: for warranty queries, complex repairs, or any section you cannot identify with certainty, contact LEKI UK: [email protected] | +44 (0)1250 710414.
► Not Compatible With
✗ SLS (Super Lock System) poles — twist-lock, not compatible with Speed Lock Plus sections
✗ Speed Lock 2 (SL2) poles — separate product line, different locking geometry
✗ Speed Lock 2 Plus (SL2+) poles — 2015+ generation; SPL sections are not interchangeable
✗ Poles with a different section specification — this section is 14 mm diameter and 462 mm
BEFORE YOU ORDER — FOUR-POINT CHECK
✓ Printed length: the printed length on your existing middle section must read 462 mm
✓ Diameter: section diameter must be 14 mm (check the markings on the existing section)
✓ Locking system: confirm your poles use Speed Lock Plus (SPL)
✓ Construction: confirm 3-section telescopic (Vario); not suitable for folding (FX) or 2-section poles
